Insulating glass INSULATE P7B and P8B

  Lagerbestand gering. Lieferzeit auf Anfrage.
Artikelnummer:  72000

Hammerglass insulating glass INSULATE P7B and P8B

Hammerglass INSULATE is an insulating glass system with double or triple glazing and your choice of glass for the inner pane.Hammerglass INSULATE can be integrated into existing glazing.Its low weight and high security class offer numerous possibilities for glazing in existing structures.Hammerglass INSULATE offers excellent resistance to burglary and vandalism.

We're testing the strength!

We thoroughly test all our products.Watch the film where we perform a forcible strength test on 6mm Hammerglass versus a standard police station safety glass (25mm laminated glass).

  • A burglary lasts 10 minutes.
  • Half of all break-ins happen through the window.
  • In general, windows and glass surfaces are the weakest point in the house, followed by doors.

Hammerglass INSULATE

Hammerglass INSULATE is manufactured in all available insulating glass versions, usually with Hammerglass on the outside.For the second and/or third pane of glass, the customer can choose from any type of glass available on the market.With the installation of Hammerglass as the inner glass pane in the insulating glass cassette, the system offers protection against splinter injuries in the event of an explosion.

Hammerglass INSULATE also has excellent sound insulation properties, a low U-value and sun protection properties.Also available with heat reducing Hammerglass IR, a lightly tinted Hammerglass that offers 45% heat reduction.

All window manufacturers/aluminum fabricators are able to supply windows or doors with Hammerglass panes.We have cooperation agreements with leading window manufacturers.
  • Protects against burglary and vandalism - personal protection
  • safety classified double glazing system
  • Insulating glazing for installation in new or existing window frames
  • Can be configured with all types of window glass on the market
  • Available with heat-reducing Hammerglass IR
  • 5 year guarantee on the insulation
  • Excellent soundproofing
  • Security class EN 356 P8B in the configuration /6mm Hammerglass/12mm spacing/4-4-1 laminated glass/
  • Provides excellent protection against burglary and vandalism for schools, public buildings, industrial buildings, etc.
  • Also suitable for private houses

Installation and guarantee

Hammerglass INSULATE is only installed by recommended installers to ensure the highest quality.All Hammerglass discs are laser marked with a logo and production number to ensure traceability for internal quality assurance purposes and safety in the event of warranty issues.

Additional information on the product Hammerglass insulating glass P7B and P8B

Supplier: Hammerglass AB

SPECIFICATIONS g value U value Class
INSULATE
HG06-16-FE4 0.70 1.53 P7B
HG08-16-FE4 0.70 1.53 P8B
HG06-14-F4-16-FE4 0.62 1.19 P7B
HG08-12-F4-16-FE4 0.61 1.19 P8B
FE4-14-HG06-16-FE4 0.58 0.87 P7B
HG06-14-F4-16-SFE4 0.53 0.98 P7B
SFE4-14-HG06-16-SFE4 0.52/0.58 0.66 P7B
HG06-16-44,2E 0.70 1.50 P8B
INSULATE SUNERGY
HG06-16-SuCl6 0.67 1.86 P7B
HG06-14-SuCl6-16-F4 0.52/0.58 1.37/1.35 P7B
INSULATE PLANIBEL
PE N71/39-15-HG06-14-SFE4 0.38/0.37 0.65 P7B
Abbreviations
HG = Hammerglass Clear
FE = Float Energy glass
SFE = Soft coated Float Energy glass
SuCl = Sunergy Clear
PE = Planibel Energy Solar Protection glass
Source: Hammerglass AB

Certifications: Link BlogeintragWiki Hammerglass Certifications
